Pumps are good devices used in various industries to move fluids, such as liquids, gases, or slurries, by mechanical action. They are good components in many applications, from domestic water supply systems to complex industrial processes.
Advantages of Pump
Versatility
One of the primary advantages of a pump is its versatility. Pumps are designed to handle a wide range of fluids, including water, oil, chemicals, and gases. This adaptability makes them suitable for use in various industries, such as manufacturing, agriculture, and healthcare.
Handling Different Fluids
Pumps can manage different types of fluids, including those with varying viscosities and temperatures. This flexibility allows them to be used in diverse applications, from pumping water in irrigation systems to handling aggressive chemicals in industrial processes.
Energy Efficiency
Pumps are designed to be energy-efficient, helping to reduce operational costs and environmental impact. Modern pumps are equipped with advanced technologies that optimize energy consumption, ensuring that they operate effectively without wasting power.
Reliability and Durability
Pumps are known for their reliability and durability. This robustness ensures that pumps can provide consistent performance over extended periods, reducing the need for frequent maintenance or replacements.
Longevity
The durability of pumps translates to a longer lifespan, which means that they can serve their purpose effectively for many years. This longevity is a good factor in industries where uninterrupted operation is essential.
Selling Points of Pump
Customizable Options
Pumps offer a range of customizable options to meet specific needs. Manufacturers provide various sizes, materials, and configurations to ensure that pumps can be tailored to fit the unique requirements of different applications.
Material Choices
Customers can choose pumps made from materials that are suited to their application, such as stainless steel for corrosive environments or cast iron for heavy-duty use. This customization ensures performance and longevity.
Advanced Technology
Modern pumps are equipped with advanced technologies that enhance their performance and efficiency. Features such as variable speed drives, smart sensors, and remote monitoring capabilities make pumps more efficient and easier to manage.
Smart Sensors
Smart sensors in pumps allow for real-time monitoring of performance parameters, enabling predictive maintenance and reducing the risk of unexpected failures. This technology ensures that pumps operate optimally and reliably.
Environmental Considerations
Pumps designed with environmental considerations in mind help reduce the ecological impact of industrial operations. Energy-efficient designs and materials that minimize waste contribute to more sustainable practices.
Reduced Emissions
Energy-efficient pumps help reduce carbon emissions by consuming less power. This reduction in energy usage aligns with global efforts to decrease the environmental footprint of industrial activities.
Applications of Pump
Water Supply and Treatment
Pumps play a good role in water supply and treatment systems. They are used to transport water from sources such as wells and rivers to treatment plants and then distribute it to residential, commercial, and industrial areas.
Irrigation Systems
In agriculture, pumps are essential for irrigation systems, ensuring that crops receive adequate water for growth. They help maintain consistent water pressure and flow, which is good for efficient irrigation.
Industrial Processes
In industrial settings, pumps are used in various processes, including chemical processing, oil and gas production, and manufacturing. They help transfer fluids, maintain pressure, and ensure that processes run smoothly.
Chemical Processing
Pumps are good in chemical processing plants, where they handle the transfer of chemicals, mixing, and dosing. Their ability to handle aggressive and corrosive fluids makes them good in this sector.
HVAC Systems
Pumps are integral components of heating, ventilation, and air conditioning (HVAC) systems. They circulate water or coolant to regulate temperatures in residential, commercial, and industrial buildings.
Cooling Towers
In HVAC systems, pumps are used in cooling towers to circulate water and maintain the desired temperature. Their efficiency and reliability are good for the effective operation of these systems.
Medical Devices
Pumps are used in medical devices such as infusion pumps and dialysis machines. Their accuracy and reliability are good for patient safety and effective treatment.
Conclusion
Pumps are versatile devices with numerous advantages, selling points, and applications across different industries. Their ability to handle various fluids, energy efficiency, reliability, and advanced technology make them good in modern industrial and domestic applications. Whether it's for water supply, industrial processes, HVAC systems, or healthcare, pumps play a good role in ensuring the efficient and reliable movement of fluids.
| Item No. | CP-180 |
| Pump Type | piston pump |
| Max Pressure | 70Mpa |
| Working Pressure | 63Mpa |
| Flow Rate | 1.2ml each |
| Oil Capacity | 0.35L |
| Length of oil tube | 0.9M |
| Weight | 4KG |
| Application | Driving single-acting hydraulic cylinder. |
| Options (Extra cost required) |
pressure gauge |
| Item No. | CP-700 |
| Pump Type | piston pump |
| Max Pressure | 70Mpa |
| Working Pressure | 63Mpa |
| Flow Rate | high pressure: 2.3ml each low pressure: 13ml each |
| Oil Capacity | 0.9L |
| Length of oil tube | 1.8M |
| Weight | 12KG |
| Application | Driving single-acting hydraulic cylinder. |
| Options (Extra cost required) |
pressure gauge |
| Item No. | CP-700-2 |
| Pump Type | piston pump |
| Max Pressure | 70Mpa |
| Working Pressure | 63Mpa |
| Flow Rate | high pressure: 2.3ml each low pressure: 13ml each |
| Oil Capacity | 2L |
| Length of oil tube | 1.8M |
| Weight | 12KG |
| Application | Driving single-acting hydraulic cylinder. |
| Options (Extra cost required) |
pressure gauge |
| Item No. | CP-700F |
| Pump Type | piston pump |
| Max Pressure | 70Mpa |
| Working Pressure | 63Mpa |
| Flow Rate | high pressure: 2.3ml each low pressure: 13ml each |
| Oil Capacity | 1.2L |
| Length of oil tube | 1.8M |
| Weight | 11/13KG |
| Application | Driving single-acting hydraulic cylinder. |
| Options (Extra cost required) |
pressure gauge |
| Item No. | CP-700-2F |
| Pump Type | piston pump |
| Max Pressure | 70Mpa |
| Working Pressure | 63Mpa |
| Flow Rate | high pressure: 2.3ml each low pressure: 13ml each |
| Oil Capacity | 2.8L |
| Length of oil tube | 1.8M |
| Weight | 14/16KG |
| Application | Driving single-acting hydraulic cylinder. |
| Options (Extra cost required) |
pressure gauge |
| Item No | CP-800 |
| Output pressure Low pressure | 20kg/cm2 |
| Output pressure High pressure | 700kg/cm2 |
| Oil quantity per work Low pressure | 13cc |
| Oil quantity per work High pressure | 2.3cc |
| Oil storage | 2800cc |
| Size | 670x210x21 0mm |
| Weight | 7.5kg |
| package | carton |
| Model No. | DB075-S1 |
| Motor Power | 0.75Kw |
| High Pressure | 70 MPa |
| High-Pressure Flow | 0.9L/min(above 7 Mpa) |
| Package | Wooden Case |
| Working Voltage | 220V/380V |
| Low Pressure | 7Mpa |
| Low-Pressure Flow | 5L/min(below 7 Mpa) |
| NetWeight | 32Kg(Without oil) |
| Oil Reserves | 7L(You can increase the oil tank,oil pump using 15# hydraulic oil,15# below the thinner the better) |
| Model No. | DB075-S2 |
| Motor Power | 0.75Kw |
| High Pressure | 70 MPa |
| High-Pressure Flow | 0.9L/min(above 7 Mpa) |
| Package | Wooden Case |
| Working Voltage | 220V/380V |
| Low Pressure | 7Mpa |
| Low-Pressure Flow | 5L/min(below 7 Mpa) |
| NetWeight | 32Kg(Without oil) |
| Oil Reserves | 7L(You can increase the oil tank,oil pump using 15# hydraulic oil,15# below the thinner the better) |
| Model No. | DB075-D3 |
| Motor Power | 0.75Kw |
| High Pressure | 70 MPa |
| High-Pressure Flow | 0.9L/min(above 7 Mpa) |
| Package | Wooden Case |
| Working Voltage | 220V/380V |
| Low Pressure | 7Mpa |
| Low-Pressure Flow | 5L/min(below 7 Mpa) |
| NetWeight | 32Kg(Without oil) |
| Oil Reserves | 7L(You can increase the oil tank,oil pump using 15# hydraulic oil,15# below the thinner the better) |
| Model No. | DB075-D2 |
| Motor Power | 0.75Kw |
| High Pressure | 70 MPa |
| High-Pressure Flow | 0.9L/min(above 7 Mpa) |
| Package | Wooden Case |
| Working Voltage | 220V/380V |
| Low Pressure | 7Mpa |
| Low-Pressure Flow | 5L/min(below 7 Mpa) |
| NetWeight | 32Kg(Without oil) |
| Oil Reserves | 7L(You can increase the oil tank,oil pump using 15# hydraulic oil,15# below the thinner the better) |
| Model No. | DB150-D1 |
| Voltage | 220V-380V |
| Frequency | 50Hz |
| High pressure | 70 MPa |
| Low pressure | 10 MPa |
| Oil storage | 30L(customizable) |
| Power | 1.5Kw |
| Speed | 1400r/min |
| High-pressure flow | 1.7L/min |
| Low-pressure flow | 7.9L/min |
| Overall dimensions | 400x300x550mm |
| Oil of | Anti-wear hydraulic oil below 32# or 7-15# hydraulic transmission oil |
| Model No. | DB150-S2 |
| Motor Power | 1.5Kw |
| High Pressure | 70Mpa |
| High-Pressure Flow | 1.7Umin(above 7Mpa) |
| Speed | 1400r/min |
| Package | Wooden Case |
| Working Voltage | 220V/380V |
| Low Pressure | 10Mpa |
| Low-Pressure Flow | 7.9L/min(below 7Mpa) |
| Net Weight | 45Kg(Without oil) |
| Gross Weight | 51Kg(Contain the packaging) |
| Oil Reserves | 10L30L(Can increase the oil tank oil pump using 15# hydraulic oil, 15# below the thinner the better) |
